| PPM-C412D2-2-0-ST | PC/104-Plus Single Board Computer with heat spreader only |
| PPM-C412D2-2-1-ST | PC/104-Plus Single Board Computer with heat spreader plus heat sink |
PPM-C412
Description
WINSYSTEMS’ PPM-C412 single board computer (SBC) is a PC104-Plus form factor SBC featuring the latest generation DMP® Vortex86DX3® SOC processor. Its small size, low power, rugged design, and extended operational temperature make it a great fit for industrial IoT applications and embedded systems in the industrial control, transportation, Mil/COTS, and energy markets.
Features
- Performance for Industrial IoT Applications
- 1 GHz DMP Vortex86DX3 Processor (Dual core) CPU
- 2 GB DDR3-LV System RAM
- Low Power
- 10 Year Availability
- Rugged Design for Demanding Environments
- -40°C to +85°C Operating Temperature Range
- PC/104-Plus Small Form Factor
- Shock and Vibration Tested
- Connectivity and I/O for Embedded Systems
- Dual Ethernet (1x Fast Ethernet, 1x Gigabit)
- 4x USB 2.0
- 24x GPIO 5V with Event Sense
- 4x Serial Ports (2x RS-232, 2x RS-232/422/485)
- Parallel Port LPT
- Audio
- Graphics Support
- Dual video output (VGA, LVDS with digital backlight dimmer)
- PPM-C412 Datasheet (PDF)
Datasheets
- PPM-C412 Product Manual (PDF)
Product Manuals
- DOS Example C Functions - WS16C48 Digital I/O
- Linux - Kernel 4+ - WS16C48 Digital I/O
- Windows 7/10 32bit- WS16C48 Digital I/O
- Windows 7/10 64bit - WS16C48 Digital I/O
Drivers
- BIOS - 41220223.zip
BIOS
- PPM-DC-ATX-P | PC104-Plus ATX DC/DC power supply
- PCM-DC-AT512-P | PC104 +5V +/-12V DC/DC power supply
- ISM-DC-AT512-P | Industrial +5V and +12V DC/DC power supply
- PS-RS50-5 | 50W Universal A/C Switching Power Supply with +5V DC output
- PS-RS25-5 | 25W power supply +5V Output
- CBL-SPL-001-14 | Video – (LVDS) Unterminated, 14″
- CBL-PWR-117-12 | Power – SATA Power
- CBL-SATA-701-20 | SATA – Data (Latching), 20″
- ADP-IO-USB-002 | Termination Board – USB, Dual Type A
- CBL-USB4-002-12 | USB – Dual 2mm Molex Milli-Grid, 12″
- CBL-USB4-000-14 | USB – Unterminated, 14″
- CBL-LED3-001-12 | Ethernet – Remote LED, 1mm Molex Pico-Clasp, 12″
- CBL-LED3-000-14 | Ethernet – Remote LED, Unterminated, 14″
- CBL-ENET1-302-12 | Ethernet – RJ45 Female, 12″
- CBL-DIO24-002-12 | Digital I/O – 50-pin IDC Female, 12″
- CBL-DIO24-001-12 | Digital I/O – Molex Pico-Clasp, 12″
- CBL-251-G-1-1.5 | Multi-I/O – KYB, Mouse, Serial, LPT, Ethernet and Misc, 18″
- CBL-251-0 | Multi-I/O – Unterminated, 24″
- CBL-234-G-1-1.375 | Video – VGA (DB15), 16.5″
- CBL-174-G-1-1.5 | Power – Unterminated, 18″
- CBL-SET-412-1 | Cable Set for PPM-C412
- BAT-LTC-E-36-27-1 | External 3.6V, 2400 mAH battery
- BAT-LTC-E-36-16-1 | External 3.6V, 1650 mAH battery
- RISER-PPM-1 | Spacer board with PCI-104 Connector
- RISER-PCM-1 | Spacer board with PC/104 Connector
